SALAMI/薩拉米 雙聯泵 2PE16/8 3/D-P28P1-PIB
外殼鋁體
鑄鐵法蘭和蓋
雙軸密封
2齒整體齒輪
可提供法蘭
可支持軸承
內置閥后覆蓋范圍廣
緊湊的設計
意大利SALAMI齒輪泵公司介紹：
SALAMI公司建立在1956年,被稱為在歐洲主要的和額外的歐洲構造函數的部門。
在SALAMI的世界上每一個目標僅僅是一個起點，另一個步驟，以便將克服為美好未來。
歷史背景
1956–建立SALAMI，生產第一泵；
1975–建立意大利SALAMI，位于維琴察；
1977–建立了法國子公司，法國SALAMI；
1977–建立了法國子公司，法國SALAMI；
1985–建立西班牙子公司，西班牙SALAMI，美國；
2002–成立美國分公司，水力學，SALAMI；
2002–建立SALAMI組；
2008–開放的中國上海代表處的任務。
SALAMI的使命是滿足客戶的需求完全和迅速的答案，解決問題，客戶的援助，總額和高質量的產品和先進的新技術研究。
SALAMI策略的重點是提高配電系統和計算機網絡，自動化的投資，產品更新和支持客戶的技術，商務和客戶服務
SALAMI產品介紹：
SALAMI薩拉米。Salami gear pumps, gear motors and directional control valves
Standard hydraulic gear pump 液壓齒輪泵
Hydraulic valve: Monoblock valve 方向控制閥
Hydraulic gear pump in alluminium alloy 鋁合金齒輪泵
Hydraulic valve: Sectional valve 截止閥
Hydraulic valve: Pressure compensated valve壓力補償閥
Gear Pumps and Motors
|
|
|
| B series |
Gear pumps and motors in aluminium alloy.Displacements from 1 to 142 cm3/rev. (from 0.06 to 8.55 cu.in rev.)
Maximum pressure up to 300 bar (4300 psi) Available in European, German and u.s. standards.
|
ADVANTAGES :
Low noise level Easy combination in multiple units High efficiency Considerable reliability. |
|
G
R
O
U
P
|
Type
|
Displacement
cm3/rev.
cu.in/.rev.
|
Working
Pressure P1
bar/psi
|
Peak
Pressure P3
bar/psi
|
Max/Min
Speed
rpm
|
1
|
1PB 1.1
|
1.06/0.06
|
210/3000
|
260/3750
|
1000/5000
|
1PB 1.3
|
1.25/0.07
|
210/3000
|
260/3750
|
1000/5000
|
1PB 1.6
|
1.65/0.09
|
210/3000
|
260/3750
|
1000/5000
|
1PB 2
|
2.12/0.12
|
210/3000
|
260/3750
|
1000/5000
|
1PB 2.5
|
2.65/0.16
|
210/3000
|
260/3750
|
1000/5000
|
1PB 3
|
3.18/0.19
|
210/3000
|
260/3750
|
1000/5000
|
1PB 3.5
|
3.71/0.22
|
190/2715
|
240/3450
|
1000/5000
|
1PB 4
|
4.24/0.25
|
190/2715
|
210/3000
|
800/4000
|
1PB 4.5
|
4.77/0.28
|
180/2600
|
200/2900
|
800/4000
|
1PB 5.5
|
5.83/0.35
|
180/2600
|
200/2900
|
800/4000
|
2
|
2PB 4.5
|
4.6/0.35
|
250/3600
|
300/4300
|
600/4000
|
2PB 6.2
|
6.5/0.37
|
250/3600
|
300/4300
|
600/4000
|
2PB 8.3
|
8.2/0.50
|
250/3600
|
300/4300
|
500/3500
|
2PB 11.3
|
11.5/0.68
|
250/3600
|
300/4300
|
500/3500
|
2PB 13.8
|
13.8/0.84
|
250/3600
|
300/4300
|
500/3500
|
2PB 16
|
16.6/0.97
|
250/3600
|
300/4300
|
400/3000
|
2PB 19
|
19.4/1.15
|
220/3140
|
260/3750
|
400/3000
|
2PB 22.5
|
22.9/1.37
|
200/2900
|
240/3450
|
400/2750
|
2PB 26
|
25.8/1.58
|
180/2600
|
220/3140
|
400/2500
|
2.5
|
2.5PB 16
|
16/0.96
|
250/3600
|
300/4300
|
600/3000
|
2.5PB 19
|
19.3/1.15
|
250/3600
|
300/4300
|
600/3000
|
2.5PB 22
|
22.2/1.35
|
250/3600
|
300/4300
|
500/3000
|
2.5PB 25
|
25.2/1.54
|
250/3600
|
300/4300
|
500/3000
|
2.5PB 28
|
27.3/1.63
|
250/3600
|
300/4300
|
500/3000
|
2.5PB 32
|
32.5/1.95
|
230/3600
|
260/3750
|
500/3000
|
2.5PB 38
|
38.2/2.29
|
200/2900
|
240/3450
|
400/2750
|
2.5PB 44
|
44.3/2.65
|
180/2600
|
210/3000
|
400/2000
|
3
|
3PB 21
|
20.6/1.25
|
250/3600
|
300/4300
|
600/3000
|
3PB 27
|
27/1.65
|
250/3600
|
300/4300
|
600/3000
|
3PB 33
|
33.5/2.00
|
250/3600
|
300/4300
|
500/3000
|
3PB 38
|
38.7/2.36
|
250/3600
|
300/4300
|
500/3000
|
3PB 46
|
46.9/2.83
|
245/3500
|
275/3950
|
500/2750
|
3PB 55
|
54.1/3.3
|
210/3000
|
250/3600
|
400/2500
|
3PB 65
|
63.1/3.85
|
200/2900
|
240/3450
|
400/2250
|
3.5
|
3.5PC 55
|
54.8/3.34
|
250/3600
|
300/4300
|
500/2750
|
3.5PC 64
|
63.2/3.85
|
250/3600
|
300/4300
|
500/2750
|
3.5PC 75
|
74.7/4.55
|
230/3300
|
280/4000
|
400/2500
|
3.5PC 87
|
88/5.36
|
210/3000
|
260/3750
|
400/2250
|
4
|
4PB 68
|
68.7/4.12
|
250/3600
|
300/4300
|
600/3000
|
4PB 82
|
82.5/4.95
|
250/3600
|
300/4300
|
600/3000
|
4PB 103
|
102.5/6.15
|
225/3250
|
280/4000
|
500/2500
|
4PB 125
|
125/7.5
|
210/3000
|
250/3600
|
500/2500
|
4PB 142
|
142.5/8.55
|
200/2900
|
240/3450
|
500/2400
|
|
|
Directional Control Valves
|
|
|
|
|
|
ADVANTAGES :
Very low leakage between spool and body
Very good metering characteristics
Spools interchangeability |
|
| Monoblock |
Deliveries up to 75 lt/min (21 US gpm) and
Pressures up to 315 bar (4560 psi)
High resistance cast iron bodies from
1 to 6 spools
Specifications: hardened and chrome plated steel
Alloy spools ; optional auxiliary valve on B port side.
|
|
|
| Modular valves |
Deliveries up to 250 It/min ( 70 US gpm )
Pressures up to 350 bar (5100 psi)
Available in LOW VERSION, the cheapest one with Optional auxiliary valves on the B port side, and in HIGH VERSION with optional auxiliary valves on A And B port High resistance cast iron body with 1 to 10 sections.
Specifications: hardened and chrome plated steel
Alloy spools
|
|
|
|
|
